The Saber™ C6 is a miniature GNSS/INS integrated navigation module that provides precise positioning, velocity, acceleration and attitude information in complex and harsh environments.
Autonomous Fault Inspection
Saber™ C6 fusion algorithm can provide high precision position & absolute direction data, helping unmanned inspection robots to reach fault location quickly.
Self-Driving Car
Our multi-sensor fusion algorithm with high precision output help our customers upgrade their autonomous vehicle capability from SAE Driving Mode Level 1 ("hands on") to Level 3 ("eyes off").
Autonomous Delivery
Saber™ C6 can provide high precision position & absolute direction data, solving the autonomous "Last-Mile Delivery" service problem.
Unmanned Plant Protection
Precise positioning & fast real-time attitude data help unmanned plant protection drones to work consistently & efficiently without fearing bad weather.
Integrated in all Saber™ modules, the Boson™ is a powerful fusion algorithm engine that performs ultra-high calculations, ensuring high data throughput while maintaining high accuracy with very low drift errors that meets high performance standards for critical applications.
Saber™ built-in inertial measurement modules with satellite/inertial depth fusion technology greatly improve the reliability, accuracy and dynamics of the system.
The Saber™ features an onboard high sensitivity 72-channel GNSS receiver which also provides an interface for connecting an external GNSS antenna.
Saber™ C6 Module supports integrating external odometer data input to accurately position the vehicle in the loss of GNSS signal.
With the intergation of multi-sensor & on-board Barometer, it delivers high accuracy height information with sub-meter accuracy.
The Saber™ C6 unique dual gyroscope technology, through the latest Boson™ engine, creates more accurate, more stable output and the Gyro Redunancy feature is ideal for mission critical applications.
All Saber™ modules undergo factory multi-calibration and total alignment to ensure product accuracy and that it can perform automatic real-time calibration and environmental compensation during product deployment.
Specification
Development
For fast and easy application development:
Evaluation Board Kit (EVK)
Plug and Play kit with:
» Simple USB connection for data and power
» I2C, SPI and UART data connections
» Interface to Raspberry PI and other IoT platforms
Software SDK
Windows-based software allows:
» Real-time data visualization
» Simple configuration profiles
» Data analysis with time line
» Export data to various formats
» C library, code source examples are included
